Description
PREORDER – This is a pre-sale/pre-order for the first series production of the Elephant Cargo Fork. Shipping will take place earliest after production. Estimated delivery time: 6 months (changes may apply)! Earliest expected month of shipping: May 2026!
ONLY ONE SET PER BUYER! Shops or communities wishing to purchase multiple items should please indicate this in the message function when placing their order! We will then send a separate invoice, and the actual shipping costs will only be calculated on the shipping date (possibly shipping costs).
Please make sure your frame fits the technical requirements before you buy. These two videos should help you out:
– compatible frames: https://youtu.be/t1c_b2Wh_c0
– Elephant Cargo Fork specifications: https://youtu.be/6McqkOpJXC8
With our kit, you can convert a steel frame with a 1 1/8″ headset into a compact cargo bike. Since the loading area can be folded, you are extremely flexible when on the road, whether for your daily commute, urban parking, or storage at home. When folded up, smaller bike bags can be attached and the flat loading area can carry 20 kg. So even a bike packing trip is no problem! Feel free to watch the video to make sure our kit fits your frame.
Scope of delivery:
– cargo rack (base with two pre-installed wings)
– 20″ Gabel mit IS-Scheibenbrems-Aufnahme
– downtube clamp (pre-installed onto the base)
– 2x shims to protect the downtube between clamping
Technical specifications:
– 600x330mm foldable cargo plattform (fits 600x400mm euroboxes)
– holds two small commuter big-bags (Ortli** City)
– 1 1/8 inch fitting (steel-frame only!)
– 460 mm axle to crown (20“ wheel axle to 26” frame head tube, i.e. for +/-400 mm AC on a 26" frame)
– 74° headtube to plattform angle
– 20 inch wheel (not included), holds 54mm tires
– 100mm quick release axle
– IS disc brake standard
– maximum 40mm downtube diameter!
– custom downtube TPU bushing included
Please read the instructions:
MANUAL WILL BE PROVIDED ON THE SHIPPING DATE! (Incorrect torque specifications in the manual from December 2025!)
